HMC338LC3B - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

HMC338LC3B
Manufacturer

ADI
ChipWorker Part#

CW5305169
Category

RF Module
Package

QFN-12
Description

Up/Down Conv Mixer 4V 34000MHz 12Pin QFN Bulk
Documentation

Datasheet

HMC338LC3B Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

HMC338LC3B Specifications

Attribute	Attribute Value

Part Number	HMC338LC3B
Manufacturer	ADI
ChipWorker Part#	CW5305169
Category	RF Module
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	12 Pin
Case/Package	QFN-12
Frequency	24GHz ~ 34GHz
Supply Current	29 mA
Power Dissipation	227 mW
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	238 mW
Supply Voltage	3V ~ 4V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
ECCN Code	5A991.b

Product Description

* Integrated LO Amplifier: -5 dBm Input * Sub-Harmonically Pumped (x2) LO * High 2LO/RF Isolation: 33 dB * Die Size: 1.32 x 0.97 x 0.1 mm
