L77SDE09S - Amphenol
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoL77SDE09S
-
ManufacturerAmphenol
-
ChipWorker Part#CW9742446
-
CategoryD-Sub Connector, D-Sub Standard Connector, Connector D-Subminiature
-
PackageSOD
-
DescriptionPlug; D-Sub; PIN:9; female; soldering; for cable; gold flash; 250V
-
DocumentationDatasheet
