BAV99SH6327XTSA1 - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

BAV99SH6327XTSA1
Manufacturer

Infineon
ChipWorker Part#

CW9261159
Category

Diode Array, TVS Diode Array
Package

SOT-363-6
Description

Diode: switching; SMD; 85V; 0.2A; 0.25W(1/4W); Package: reel, tape; SOT363
Documentation

Datasheet

BAV99SH6327XTSA1 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

BAV99SH6327XTSA1 Specifications

Attribute	Attribute Value

Part Number	BAV99SH6327XTSA1
Manufacturer	Infineon
ChipWorker Part#	CW9261159
Category	Diode Array, TVS Diode Array
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	SOT-363-6
Power Rating	250 mW
Load Current	0.2 A
Forward Voltage	1.25V @150mA
Power Dissipation	250 mW
Reverse recovery time	4 ns
Forward Current	200 mA
Maximum Forward Voltage (Max)	1.25 V
Forward Current (Max)	200 mA
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature	150℃ (Max)
Power Dissipation (Max)	250 mW
	expand all
Size-Length	2 mm
Size-Width	1.25 mm
Size-Height	0.9 mm
Material	Silicon
Operating Temperature	-65℃ ~ 150℃
Product Lifecycle Status	Not Recommended for New Designs
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

Summary of Features:
For high-speed switching applications
Series pair configuration
BAV99S / U: For orientation in reel see
package information below
Pb-free (RoHS compliant) package1)
Qualified according AEC Q101
