Part No

HMC347A
Manufacturer

ADI
ChipWorker Part#

CW3972040
Package

SMD
Description

RF Switch SPDT 0MHz to 20GHz 40dB 10Pin Die Tray
Documentation

Datasheet

HMC347A Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

HMC347A Specifications

Attribute	Attribute Value

Part Number	HMC347A
Manufacturer	ADI
ChipWorker Part#	CW3972040
Documentation	Datasheet
Number of Pins	10 Pin
Case/Package	SMD
Frequency	20000 MHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-55 ℃
	expand all
Operating Temperature	-55℃ ~ 85℃
Product Lifecycle Status	Pre-Release
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
ECCN Code	EAR99

Product Description

Product Details
The HMC347A is a broadband non-reflective GaAs pHEMT SPDT MMIC chip. Covering DC to 20 GHz, the switch offers high isolation and low insertion loss. The switch features over 52 dB isolation at lower frequencies and over 40 dB at higher frequencies due to the implementation of on-chip via hole structures. The switch operates using two negative control voltage logic lines of -5/0V, requires no Vee and has no current consumption. The switch operates down to DC. The chip features coplanar I/Os that allow 100% RF testing prior to delivery to the customer.
**Applications**
Fiber optics
Microwave radio
Military
Space
VSAT
### Features and Benefits
High Isolation: >40 dB @ 20 GHz
Low Insertion Loss: 2.1 dB @ 20 GHz
Non-Reflective Design
Small Size: 1.22 × 0.85 × 0.1 mm
