IPD025N06N - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

IPD025N06N
Manufacturer

Infineon
ChipWorker Part#

CW52285777
Category

MOSFET, MOSFET Transistor
Package

TO-252-3
Description

DPAK N-CH 60V 90A
Documentation

Datasheet

IPD025N06N Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

IPD025N06N Specifications

Attribute	Attribute Value

Part Number	IPD025N06N
Manufacturer	Infineon
ChipWorker Part#	CW52285777
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	TO-252-3
Number of Channels	1 Channel
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	0.0021 Ω
Polarity	N-Channel
Power Dissipation	167 W
Threshold Voltage	2.8 V
Drain to Source Voltage (Vds)	60 V
Breakdown Voltage (Drain to Source)	60 V
Continuous Drain Current (Ids)	90A
Rise Time	20 ns
Input Capacitance (Ciss)	5200pF @30V(Vds)
Fall Time	12 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	3W (Ta), 167W (Tc)
	expand all
Size-Length	6.5 mm
Size-Width	6.22 mm
Size-Height	2.3 mm
Operating Temperature	-55℃ ~ 175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

Summary of Features:
Optimized for synchronous rectification
40% lower R DS(on) than alternative devices
40% improvement of FOM over similar devices
RoHS compliant - halogen free
MSL1 rated
Benefits:
Highest system efficiency
Less paralleling required
Increased power density
System cost reduction
Very low voltage overshoot
