IR1176 ,FET Driver - International Rectifier

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

33 points

Part No

IR1176
Manufacturer

International Rectifier
ChipWorker Part#

CW446482440
Category

FET Driver
Package

DIP-20
Description

Synchronous Rectifier Driver, 2MHz Max Frequency, 500ns leadtime, Schmitt Trigger Input in a 20 Lead DIP package
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

Price on Request

Buy IR1176

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

IR1176 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

IR1176 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	IR1176
Manufacturer	International Rectifier
ChipWorker Part#	CW446482440
Category	FET Driver
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	20 Pin
Case/Package	DIP-20
Number of Outputs	2 Output
Supply Voltage	4V ~ 5.25V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Unknown
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead

Similar & Replacement Parts

Product Description

Vdd 5Vdc
IO+/- (peak) 4A/4A
Fmax 2MHz
Max lead time 500nsec
Description
The IR1176 is a high speed CMOS controller designed to drive N-channel power MOSFETs used as synchronous rectifiers in high current, high frequency forward converters with output voltages equal or below 5VDC.
Features
• Provides constant and proper gate drive to power MOSFETs regardless of transformer output
• Minimizes loss due to power MOSFET body drain diode conduction
• Stand alone operation - no ties to primary side
• Schmitt trigger input with double pulse suppression allows operation in noisy environments
• High peak current drive capability - 4A
• High speed operation - 2MHz
• Adaptable to multiple topologies

expand all
