IR2136STRPBF ,FET Driver - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

176 points

Part No

IR2136STRPBF
Manufacturer

Infineon
ChipWorker Part#

CW2306087
Category

FET Driver
Package

SOIC-28
Description

MOSFET DRVR 600V 0.35A 6Out Hi/Lo Side 3-Phase Brdg Inv 28Pin SOIC W T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

1834 pcs In Stock
Estimated Price

$ 0.41

Buy IR2136STRPBF

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

IR2136STRPBF Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

IR2136STRPBF Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	IR2136STRPBF
Manufacturer	Infineon
ChipWorker Part#	CW2306087
Category	FET Driver
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	28 Pin
Case/Package	SOIC-28
Supply Voltage (DC)	12.0V (min)
Rise/Fall Time	125ns, 50ns
Number of Outputs	6 Output
Output Voltage	10.20 V
Output Current	350 mA
Number of Channels	2 Channel
Number of Positions	28 Position
Power Dissipation	1600 mW
Quiescent Current	1.6 mA
Rise Time	125 ns
Fall Time	50 ns
Fall Time (Max)	75 ns
Fall Time (Max)	190 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1600 mW
Supply Voltage	10V ~ 20V
Supply Voltage (Max)	20 V
Supply Voltage (Min)	12 V
	expand all
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

International Rectifier

6792 шт.

Product Description

Summary of Features:
Floating channel designed for bootstrap operation
Fully operational to +600 V
Tolerant to negative transient voltage, dV/dt immune
Gate drive supply range from 10 V to 20 V
Undervoltage lockout for all channels
Over-current shutdown turns off all six drivers
Independent 3 half-bridge drivers
Matched propagation delay for all channels
Cross-conduction prevention logic
Low side output out of phase with inputs. High side outputs out of phase
3.3 V logic compatible
Lower di/dt gate drive for better noise immunity
Externally programmable delay for automatic fault clear
Variations include IR21363
