IR2308 - International Rectifier

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

IR2308
Manufacturer

International Rectifier
ChipWorker Part#

CW364243586
RoHS

Lead free / RoHS Compliant
Description

High Voltage and High Speed power MOSFET and IGBT Half Bridge Driver in a 8Pin DIP package
Documentation

Datasheet

IR2308 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

IR2308 Specifications

Attribute	Attribute Value

Part Number	IR2308
Manufacturer	International Rectifier
ChipWorker Part#	CW364243586
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP
Supply Voltage (DC)	20.0V (max)
Output Voltage	≥10.0 V
Part Family	IR2308
	expand all
Product Lifecycle Status	Active
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

Description
The IR2308(S) are high voltage, high speed power MOSFET and IGBT drivers with dependent high and
low side referenced output channels. Proprietary HVIC and latch immune CMOS technologies enable rug
gedized monolithic construction.
Features
•Floating channel designed for bootstrap operation Fully operational to +600V Tolerant to negative transient voltage dV/dt immune
•Gate drive supply range from 10 to 20V
•Undervoltage lockout for both channels
•3.3V, 5V and 15V input logic compatible
•Cross-conduction prevention logic
•Matched propagation delay for both channels
•Outputs in phase with inputs
•Logic and power ground +/- 5V offset.
•Internal 540ns dead-time
•Lower di/dt gate driver for better noise immunity
•Also available LEAD_FREE
