ISL6269ACRZ - Intersil
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoISL6269ACRZ
-
ManufacturerIntersil
-
ChipWorker Part#CW135622696
-
CategoryDC to DC Converter
-
PackageQFN-16
-
DescriptionSoft Sw PWM Cntrlr 1Out Synchronous Buck PWM Controller 200kHz to 600kHz 16Pin QFN EP
-
DocumentationDatasheet
