ISO7342CDW ,Interface Isolator, Digital Isolator - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

108 points

Part No

ISO7342CDW
Manufacturer

TI
ChipWorker Part#

CW40450004
Category

Interface Isolator, Digital Isolator
Package

SOIC-16
Description

TEXAS INSTRUMENTS ISO7342CDW Digital Isolator, Quad, 4Channel, 31ns, 3V, 5.5V, WSOIC, 16Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 5.48

Buy ISO7342CDW

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ISO7342CDW Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ISO7342CDW Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ISO7342CDW
Manufacturer	TI
ChipWorker Part#	CW40450004
Category	Interface Isolator, Digital Isolator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	3.00V (min)
Rise/Fall Time	2.1ns, 1.7ns
Number of Channels	4 Channel
Number of Positions	16 Position
Power Dissipation	111 mW
Rise Time	2.8 ns
Isolation Voltage	3000 Vrms
Input Current (Min)	10 μA
Fall Time (Max)	2.1 ns
Fall Time (Max)	2.8 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	111 mW
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	10.3 mm
Size-Width	7.5 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The ISO7342CDW is a quad-channel Digital Isolator provide galvanic isolation up to 3000VRMS for 1 minute per UL and 4242 VPK per VDE. It has four isolated channels comprised of logic input and output buffers separated by a silicon dioxide (SiO2) insulation barrier. ISO7342 has two forward and two reverse-direction channels. Used in conjunction with isolated power supplies, it prevents noise currents on a data bus or other circuits from entering the local ground and interfering with or damaging sensitive circuitry. ISO734x has integrated noise filter for harsh industrial environment where short noise pulses may be present at the device input pins. ISO734x has TTL input thresholds and operates from 3 to 5.5V supply levels. Through innovative chip design and layout techniques, electromagnetic compatibility of ISO734x has been significantly enhanced to enable system-level ESD, EFT, surge and emissions compliance.
Integrated noise filter on the inputs
Default output high and low options
Low power consumption
Robust electromagnetic compatibility (EMC)
System-level ESD, EFT and surge immunity
Low emissions
Green product and no Sb/Br
Device has limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
