L6390DTR - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

L6390DTR
Manufacturer

ST Microelectronics
ChipWorker Part#

CW3718970
Category

FET Driver
Package

SOIC-16
Description

MOSFET DRVR 0.54V 0.43A 1Out Hi/Lo Side Half Brdg Inv/Non-Inv 16Pin SO T/R
Documentation

Datasheet

L6390DTR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

L6390DTR Specifications

Attribute	Attribute Value

Part Number	L6390DTR
Manufacturer	ST Microelectronics
ChipWorker Part#	CW3718970
Category	FET Driver
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Frequency	0.8 MHz
Rise/Fall Time	75ns, 35ns
Number of Outputs	1 Output
Output Current	290 mA
Number of Positions	16 Position
Power Dissipation	0.8 W
Quiescent Current	1000 µA
Rise Time	75 ns
Fall Time	35 ns
Fall Time (Max)	70 ns
Fall Time (Max)	120 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	800 mW
Supply Voltage	12.5V ~ 20V
Supply Voltage (Max)	20 V
Supply Voltage (Min)	12.5 V
	expand all
Size-Height	1.65 mm
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

Never worry about transistors not switching by using this L6390DTR power driver by STMicroelectronics. This device has a maximum propagation delay time of 200 ns and a maximum power dissipation of 800 mW. Its maximum power dissipation is 800 mW. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This device has a minimum operating supply voltage of 12.5 V and a maximum of 20 V. This gate driver has a minimum operating temperature of -40 °C and a maximum of 125 °C.
