LA1KN22 - Schneider Electric

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

LA1KN22
Manufacturer

Schneider Electric
ChipWorker Part#

CW14112726
Category

Industrial Relay
Package

600
Description

Contact Block, 2NO/2NC, 10A, 690VAC, 4Pole, TeSys Series, Screw
Documentation

Datasheet

LA1KN22 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

LA1KN22 Specifications

Attribute	Attribute Value

Part Number	LA1KN22
Manufacturer	Schneider Electric
ChipWorker Part#	CW14112726
Category	Industrial Relay
Documentation	Datasheet
Mounting Style	Screw
Case/Package	600
Number of Contacts	4 Contact
Current Rating	10 A
Contacts Type	4PST
Contact Current Rating	10 A
Isolation Voltage	660 V
	expand all
Weight	0.2 lb
Product Lifecycle Status	Active
RoHS	Non-Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16

Product Description

The LA1KN22 is an auxiliary contact block. This auxiliary contact blocks can snap-fit onto the front of "K" range contactors or control relays.
2NO + 2NC contact configuration
Rated operational voltage of 690VAC
Minimum switching current of 5mA at 17V
Screw clamp terminals
Compliance to UL and CSA standards
For use with TeSys K contactors
Instantaneous auxiliary contacts operation
