LC1DT40P7 - Schneider Electric

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

LC1DT40P7
Manufacturer

Schneider Electric
ChipWorker Part#

CW207434960
Category

Industrial Relay
Description

SCHNEIDER ELECTRIC / TELEMECANIQUE LC1DT40P7 Contactor, 230VAC, 4Pole, 4PNO, DIN Rail, 40A, 230V
Documentation

Datasheet

LC1DT40P7 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

LC1DT40P7 Specifications

Attribute	Attribute Value

Part Number	LC1DT40P7
Manufacturer	Schneider Electric
ChipWorker Part#	CW207434960
Category	Industrial Relay
Documentation	Datasheet
Mounting Style	DIN Rail
Operating Voltage	230 VAC
Contact Current Rating	40 A
Coil Voltage	230 VAC
Coil Voltage (AC)	230 V
Coil Voltage (DC)	110 V
Operating Temperature (Max)	60 ℃
Operating Temperature (Min)	-5 ℃
	expand all
Size-Length	91 mm
Size-Width	45 mm
RoHS	Non-Compliant
REACH SVHC Compliance	No SVHC

Product Description

The LC1DT40P7 from Schneider Electric is a TeSys D four pole contactor with normally open (NO) contacts. It is approved by UL 508, CSA C22.2, CCC, EN 60947-4-1, EN 60947-5-1, IEC 60947-4-1 and IEC 60947-5-1 standards. TeSys D contactors are designed for perfect integration in control systems. They can be used in switching equipments or relay coils, powering control equipments, powering signalling equipments and creating motor starters for any type of application.
AC-1 utilisation category
Rated operational voltage of 690VAC at 25Hz to 400Hz and 300VDC for power circuit
Rated operational current of 40A at <= 440VAC (AC-1) for power circuit
Rated impulse withstand voltage of 6KV conforming to IEC 60947
Control circuit voltage of 230VAC at 50Hz/60Hz
UL94 V-1 flammability
Ambient operating temperature range from -5°C to 60°C
IP2x front face degree of protection conforming to IEC 60529 standard
Power dissipation per pole is 3.2W (AC-1)
Rated breaking capacity of 450A at 440V for power circuit conforming to IEC 60947 standard

expand all
