LM201ADT - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

LM201ADT
Manufacturer

ST Microelectronics
ChipWorker Part#

CW8864200
Category

Operational Amplifier, OP Amp IC
Package

SOIC-8
Description

LM201A Series 22V 0.5V/µs SMT Single Operational Amplifier - SOIC-8
Documentation

Datasheet

LM201ADT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

LM201ADT Specifications

Attribute	Attribute Value

Part Number	LM201ADT
Manufacturer	ST Microelectronics
ChipWorker Part#	CW8864200
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Current	1.8 mA
Number of Circuits	1 Circuit
Power Dissipation	300 mW
Common Mode Rejection Ratio	96 dB
Slew Rate	500 mV/μs
Gain Bandwidth Product	1 MHz
Input Offset Voltage	700 µV
Input Bias Current	25 nA
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	1 MHz
Power Dissipation (Max)	300 mW
Minimum CMRR Range	80 dB
Supply Voltage	5V ~ 22V
	expand all
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

The LM101A is a general purpose operational amplifier which offers many features: supply voltages from ±5V to ±22V, low current drain, overload protection on the input and output, no latch-up when the common-mode range is exceeded, free from oscillations and compensation with a single 30pF capacitor. It has advantages over internally compensated amplifiers in that the compensation can be tailored to the particular application: slew rate of 10V/µs and bandwidth of 3.5MHz can be easily achieved.
