LM311N - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

LM311N
Manufacturer

ST Microelectronics
ChipWorker Part#

CW62687710
Category

Comparator, Analog Comparator IC
Package

DIP-8
Description

STMICROELECTRONICS LM311N Analogue Comparator, General Purpose, 1, 200ns, 5V to ± 15V, DIP, 8Pins
Documentation

Datasheet

LM311N Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

LM311N Specifications

Attribute	Attribute Value

Part Number	LM311N
Manufacturer	ST Microelectronics
ChipWorker Part#	CW62687710
Category	Comparator, Analog Comparator IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Supply Voltage (DC)	5.00V (min)
Output Current	50 mA
Supply Current	7.5 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	5 W
Quiescent Current	5.10 mA
Input Offset Voltage	7.5 mV
Input Bias Current	25 nA
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	1250 mW
Supply Voltage	5V ~ 15V
	expand all
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17

Product Description

The LM311N is a voltage comparator that has a low input current. It is also designed to operate over a wide range of supply voltages, from standard ±15V operational amplifier supplies down to the single +5V supply used for IC logic. Their output is compatible with RTL-DTL and TTL as well as MOS circuits and can switch voltages up to +50V at output currents as high as 50mA.
Wide range of supply voltages
Output compatible with RTL-DTL, TTL and MOS circuits
