SN74AHCT125N Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | SN74AHCT125N |
| Manufacturer | TI |
| ChipWorker Part# | CW2416000 |
| Category | Logic Controller, Logic IC |
| Documentation | Datasheet |
| Mounting Style | Through Hole |
| Number of Pins | 14 Pin |
| Case/Package | DIP-14 |
| Supply Voltage (DC) | 4.50V ~ 5.50V |
| Number of Outputs | 4 Output |
| Number of Circuits | 4 Circuit |
| Number of Channels | 4 Channel |
| Number of Positions | 14 Position |
| Number of Bits | 4 Bit |
| Propagation Delay Max (tpd) | 8.50 ns |
| Voltage Nodes | 5.00 V |
| Output Current Drive | -1.00 mA |
| Number of Inputs | 4 Input |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 4.5V ~ 5.5V |
| Supply Voltage (Max) | 5.5 V |
| Supply Voltage (Min) | 4.5 V |
| expand all | |
| Size-Length | 19.05 mm |
| Size-Width | 6.35 mm |
| Size-Height | 3.3 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
| ECCN Code | EAR99 |
Product Description
- The SN74AHCT125N is a quadruple Bus Buffer Gate featuring independent line drivers with 3-state outputs. Each output is disabled when the associated output-enable (OE)\ input is high. When OE\ is low, the respective gate passes the data from the A input to its Y output. To ensure the high-impedance state during power up or power down, OE\ should be tied to VCC through a pull-up resistor and the minimum value of the resistor is determined by the current-sinking capability of the driver.
