LMK61E2EVM Specifications

Attribute	Attribute Value

Part Number	LMK61E2EVM
Manufacturer	TI
ChipWorker Part#	CW9934344
Category	Microprocessor Development Kit
Documentation	Datasheet
Mounting Style	Surface Mount
Frequency	50 MHz
	expand all
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	Non-Compliant
Lead-Free Status	Not applicable
REACH SVHC Compliance Edition	2015/06/15

Product Description

The LMK61E2EVM is an ultra low jitter programmable oscillator evaluation module. This evaluation module provides a complete platform to evaluate the 90fs RMS jitter performance and configurability of the TI"s LMK61E2 ultra low jitter programmable differential oscillator with integrated EEPROM and frequency margining capabilities. It is used as a high performance clock source for jitter critical applications and can easily be customized to any user desired frequency and output format. The onboard USB to I2C interface allows for device configuration via a software GUI and requires no external input or power for device operation. The edge-launch SMA ports provide access to the LMK61E2"s differential clock output for interfacing to test equipment or reference boards using commercially available coaxial cables, adapters or baluns. This connectivity enables integrated system level testing between TI"s LMK61E2 and third-party FPGA/ASIC/SoC reference boards.
Integrated low noise 50MHz tunable crystal
Coarse frequency margining in percentage steps via I2C
Configurable output format of either LVPECL, LVDS or HCSL
Programmable output enable polarity
EEPROM allows for custom configuration for power up defaults
GUI platform for full access to LMK03328 registers and EEPROM
On-board USB to I2C programming interface
Powered over USB or externally (SMA connector)
LEDs indicators indicates device power and USB / I2C activity
Configurable output format of either LVPECL, LVDS or HCSL
