LPC2368FBD100 - NXP

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

LPC2368FBD100
Manufacturer

NXP
ChipWorker Part#

CW39498793
Category

Memory Chip
Package

LQFP-100
Description

Single-chip 16Bit/32Bit microcontrollers; up to 512KB flash with ISP/IAP, Ethernet, USB 2.0, CAN, and 10Bit ADC/DAC
Documentation

Datasheet

LPC2368FBD100 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

LPC2368FBD100 Specifications

Attribute	Attribute Value

Part Number	LPC2368FBD100
Manufacturer	NXP
ChipWorker Part#	CW39498793
Category	Memory Chip
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	100 Pin
Case/Package	LQFP-100
Clock Speed	72.0 MHz
RAM Memory Size	58K x 8
FLASH Memory Size	524288 B
Number of ADCs	1 ADC
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1500 mW
Number of DACs	1 DAC
	expand all
Size-Length	14 mm
Size-Width	14 mm
Size-Height	1.4 mm
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Unknown
Packaging	Tray
RoHS	RoHS Compliant

Product Description

General description
The LPC2364/65/66/67/68 microcontrollers are based on a 16-bit/32-bit ARM7TDMI-S CPU with real-time emulation that combines the microcontroller with up to 512 kB of embedded high-speed flash memory. A 128-bit wide memory interface and a unique accelerator architecture enable 32-bit code execution at the maximum clock rate. For critical performance in interrupt service routines and DSP algorithms, this increases performance up to 30 % over Thumb mode. For critical code size applications, the alternative 16-bit Thumb mode reducescode by more than 30 % with minimal performance penalty.
Applications
Industrial control
Medical systems
Protocol converter
Communications
