LT1962EMS8-2.5#PBF ,Voltage Regulator - Linear Technology

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

86 points

Part No

LT1962EMS8-2.5#PBF
Manufacturer

Linear Technology
ChipWorker Part#

CW64823725
Category

Voltage Regulator
Package

MSOP-8
Description

LINEAR TECHNOLOGY LT1962EMS8-2.5#PBF Fixed LDO Voltage Regulator, 1.8V to 20V, 270mV Dropout, 2.5Vout, 300mAout, MSOP-8
Documentation

Datasheet
Ships from

Moscow
Наличие

234 pcs In Stock
Estimated Price

$ 5.42

Buy LT1962EMS8-2.5#PBF

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

LT1962EMS8-2.5#PBF Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

LT1962EMS8-2.5#PBF Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	LT1962EMS8-2.5#PBF
Manufacturer	Linear Technology
ChipWorker Part#	CW64823725
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Number of Outputs	1 Output
Input Voltage (DC)	20.0V (max)
Output Voltage	2.5 V
Output Current	300 mA
Number of Positions	8 Position
Quiescent Current	0.03 mA
voltage rating	270 mV
Input Voltage (Max)	20 V
Input Voltage (Min)	1.8 V
Output Voltage (Min)	2.5 V
Output Current (Max)	300 mA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Min)	3.5 V
Input Voltage	≤20 V
	expand all
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.86 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

LM1117T-3.3/NOPB

National Semiconductor

Product Description

The LT1962EMS8-2.5#PBF is a 2.5V fixed output low noise low-dropout (LDO) Linear Regulator. The device is capable of supplying 300mA of output current with a dropout voltage of 270mV. The low 30µA quiescent current makes the device an ideal choice. Quiescent current is well controlled, it does not rise in dropout as it does with many other regulators. A key feature of the device is low output noise. With the addition of an external 0.01µF bypass capacitor, output noise drops to 20µVRMS over a 10Hz to 100kHz bandwidth. The device is stable with output capacitors as low as 3.3µF. Small ceramic capacitors can be used without the series resistance required by other regulators. Internal protection circuitry includes reverse battery protection, current limiting, thermal limiting and reverse current protection.
20µVrms Low noise (10Hz to 100kHz)
<1µA Very low shutdown current
No protection diodes needed
Stable with aluminium, tantalum or ceramic capacitors
No reverse current
Overcurrent and overtemperature protected
