LT6105IMS8#PBF ,Amplifier, Buffer IC - Linear Technology
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
106 points
-
Part NoLT6105IMS8#PBF
-
ManufacturerLinear Technology
-
ChipWorker Part#CW27045573
-
CategoryAmplifier, Buffer IC
-
PackageMSOP-8
-
DescriptionLINEAR TECHNOLOGY LT6105IMS8#PBF Current Sense Amplifier, Extended Input Range, 1 Amplifier, MSOP, 8Pins, -40℃, 85℃
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие367003 pcs In Stock
-
Estimated Price$ 0.84
Payment Methods and Delivery
{{ estimate }}
Buy LT6105IMS8#PBF
Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.
Real stock check
Best price from distributors
Engineer support
LT6105IMS8#PBF Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}xx
{{ low_stock_text }}
|
1 |
{{weeks_text}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
{{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
|
Chipworker
|
{{noList.partNo}}
{{noList.mfr}}
|
{{stockAvailability}}
{{ search_item }}
|
{{moq}} | 1 | 6 - 8 {{delivery_date}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
|||||||
{{ apiText }}{{ apiTime }}(UTC+8)
Update Data
Chipworker Certification
11+ years sourcing experience
1000+ russia customers
ISO certified supplier
Support small MOQ
*Photos of Our Actual 800 m² Warehouse
LT6105IMS8#PBF Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | LT6105IMS8#PBF | |
| Manufacturer | Linear Technology | |
| ChipWorker Part# | CW27045573 | |
| Category | Amplifier, Buffer IC | |
| Documentation | Datasheet | |
| Mounting Style | Surface Mount | |
| Number of Pins | 8 Pin | |
| Case/Package | MSOP-8 | |
| Supply Current | 250 µA | |
| Number of Circuits | 1 Circuit | |
| Number of Positions | 8 Position | |
| Common Mode Rejection Ratio | 120 dB | |
| Bandwidth | 100 kHz | |
| Input Offset Voltage | 100 µV | |
| Input Bias Current | 50 µA | |
| Operating Temperature (Max) | 85 ℃ | |
| Operating Temperature (Min) | -40 ℃ | |
| 3dB Bandwidth | 100 kHz | |
| Gain Bandwidth | 94 dB | |
| Minimum CMRR Range | 90 dB | |
| Supply Voltage (Max) | 36 V | |
| Supply Voltage (Min) | 2.85 V | |
| expand all | ||
| Size-Length | 3 mm | |
| Size-Width | 3 mm | |
| Size-Height | 0.86 mm | |
| Operating Temperature | -40℃ ~ 85℃ | |
| Product Lifecycle Status | Unknown | |
| Packaging | Each | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free | |
| REACH SVHC Compliance | No SVHC | |
| REACH SVHC Compliance Edition | 2015/12/17 |
Similar & Replacement Parts
Similar products
Product Description
- The LT6105IMS8#PBF is a precision rail-to-rail input Current Sense Amplifier with a very wide input common mode range. The LT6105 monitors unidirectional current via the voltage across an external sense resistor. The input common mode range extends from -0.3 to 44V with respect to the negative supply voltage (V-). This allows the LT6105 to operate as a high side current sense monitor or a low side current sense monitor. It also allows the LT6105 to monitor current on a negative supply voltage, as well as continuously monitor a battery from full charge to depletion. The inputs of LT6105 can withstand differential voltages up to ±44V, which makes it ideal for monitoring a fuse or MOSFET switch. Gain is configured with external resistors from 1 to 100V/V. The input common mode rejection and power supply rejection are in excess of 100dB and the input offset voltage is less than 300µV. A minimum slew rate of 2V/µs ensures fast response to unexpected current changes.
- Very wide over-the-top input common mode range
- 300µV Maximum input offset voltage
- 1% Maximum gain accuracy
- Gain configurable with external resistors
- 150µA Operating current
- 2V/µs Slew rate
- 1nA Sense input current when powered down
- 1mA Minimum full-scale output current
