MAX4886ETO+ - Maxim Integrated

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MAX4886ETO+
Manufacturer

Maxim Integrated
ChipWorker Part#

CW18952184
Category

Multiplexer IC
Package

TQFN-42
Description

Audio/Video Switch, 4 Func, 1Channel, BICMOS, 9 X 3.5MM, 0.8MM HEIGHT, LEAD FREE, TQFN-42
Documentation

Datasheet

MAX4886ETO+ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MAX4886ETO+ Specifications

Attribute	Attribute Value

Part Number	MAX4886ETO+
Manufacturer	Maxim Integrated
ChipWorker Part#	CW18952184
Category	Multiplexer IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	42 Pin
Case/Package	TQFN-42
Power Dissipation	2857.1 mW
Bandwidth	2.6 GHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	2.8 W
Supply Voltage	3V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	9.1 mm
Size-Width	3.6 mm
Size-Height	0.75 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

* Single +3.0V to +3.6V Power Supply * Low On-Resistance (RON): 8Ω (typ) * Low On-Capacitance (CON): 2.5pF (typ) * Low Skew: 20ps (typ) * 700μA Low Supply Current * 2.6GHz (typ) Ultra-High Bandwidth * 0.6dB (typ) Ultra-Low Insertion Loss * High-Frequency Companion Device to MAX4929 * Use MAX4886 and MAX4929 to Form a Complete HDMI/DVI 2:1 Switch * 42-Pin, 3.5mm x 9.0mm, Space-Saving TQFN
