MC1413DR2G ,BJT Transistor, BJT - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

213 points

Part No

MC1413DR2G
Manufacturer

ON Semiconductor
ChipWorker Part#

CW1263440
Category

BJT Transistor, BJT
Package

SOIC-16
Description

SOIC NPN 50V 0.5A
Documentation

Datasheet
Ships from

Moscow
Наличие

1282 pcs In Stock
Estimated Price

$ 0.17

Buy MC1413DR2G

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

MC1413DR2G Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

MC1413DR2G Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	MC1413DR2G
Manufacturer	ON Semiconductor
ChipWorker Part#	CW1263440
Category	BJT Transistor, BJT
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	30.0 V
Voltage Rating (DC)	50.0 V
Current Rating	500 mA
Halogen Free Status	Halogen Free
Output Voltage	50 V
Output Current	500 mA
Number of Positions	16 Position
Polarity	NPN
Breakdown Voltage (Collector to Emitter)	50 V
Continuous Collector Current	0.5A
hFE Min	1000 @350mA, 2V
DC Current Gain (hFE)	1000
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-20 ℃
Input Voltage	30 V
	expand all
Size-Length	10 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The seven NPN Darlington connected transistors in these arrays are well suited for driving lamps, relays, or printer hammers in a variety of industrial and consumer applications. Their high breakdown voltage and internal suppression diodes insure freedom from problems associated with inductive loads. Peak inrush currents to 500 mA permit them to drive incandescent lamps. The MC1413, B with a 2.7 kΩ series input resistor is well suited for systems utilizing a 5.0 V TTL or CMOS Logic.
