MC74HC14ANG ,Logic Control, Logic Gate IC - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

86 points

Part No

MC74HC14ANG
Manufacturer

ON Semiconductor
ChipWorker Part#

CW85509023
Category

Logic Control, Logic Gate IC
Package

PDIP-14
Description

Inverter Schmitt Trigger 6Element CMOS 14Pin PDIP Rail
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.31

Buy MC74HC14ANG
