NMA0515SC - muRata

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

NMA0515SC
Manufacturer

muRata
ChipWorker Part#

CW7038296
Category

DC to DC Converter, DC/DC Converter
Package

SIP-7
Description

Module DC-DC 5Vin 2Out 15V/-15V 0.033A/-0.033A 1W 5Pin SIP Tube
Documentation

Datasheet

NMA0515SC Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

NMA0515SC Specifications

Attribute	Attribute Value

Part Number	NMA0515SC
Manufacturer	muRata
ChipWorker Part#	CW7038296
Category	DC to DC Converter, DC/DC Converter
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	5 Pin
Case/Package	SIP-7
Supply Voltage (DC)	5.00 V
Power Rating	1 W
Number of Outputs	2 Output
Input Voltage (DC)	4.50V ~ 5.50V
Output Voltage	±15 V
Output Current	33 mA
Flammability Rating	UL 94 V-0
Power Dissipation	1 W
Output Power	1 W
Isolation Voltage	1 kV
Input Voltage (Max)	5.5 V
Input Voltage (Min)	4.5 V
Input Voltage (DC Max)	5.5 V
Input Voltage (DC Min)	4.5 v
Output Current (Max)	33mA, 33mA
Input Power (Max)	1 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	5 V
	expand all
Size-Length	19.5 mm
Size-Width	19.5 mm
Size-Height	10 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The NMA0515SC is a 2-output board-mount isolated DC to DC Converter ideally suited for providing dual rail supplies on primarily digital boards with the added benefit of galvanic isolation to reduce switching noise. The NMA series 1W DC/DC converter is the standard building block for on-board distributed power systems. All of the rated power may be drawn from a single pin provided the total load does not exceed 1 watt.
Efficiency up to 80%
Power density up to 0.85W/cm³
No heatsink required
Footprint from 1.17cm²
Industry standard pinout
Power sharing on output
1kVDC Isolation
Internal SMD construction
Fully encapsulated with toroidal magnetics
No external components required
MTTF up to 3.1 million hours
No electrolytic or tantalum capacitors
