OP484FSZ ,Operational Amplifier, OP Amp IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

221 points

Part No

OP484FSZ
Manufacturer

ADI
ChipWorker Part#

CW419904
Category

Operational Amplifier, OP Amp IC
Package

SOIC-14
Description

ANALOG DEVICES OP484FSZ Operational Amplifier, Quad, 4 Amplifier, 4.25MHz, 4V/µs, ± 1.5V to ± 18V, SOIC, 14Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

283276 pcs In Stock
Estimated Price

$ 0.01

Buy OP484FSZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

OP484FSZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

OP484FSZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	OP484FSZ
Manufacturer	ADI
ChipWorker Part#	CW419904
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SOIC-14
Supply Current	2.25 mA
Number of Circuits	4 Circuit
Number of Channels	4 Channel
Number of Positions	14 Position
Common Mode Rejection Ratio	60 dB
Bandwidth	4.25 MHz
Slew Rate	4.00 V/μs
Gain Bandwidth Product	4.25 MHz
Input Impedance	50.0 MΩ
Input Offset Voltage	250 µV
Input Bias Current	80 nA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	4.25 MHz
Minimum CMRR Range	60 dB
Supply Voltage (Max)	36 V
Supply Voltage (Min)	1.5 V
	expand all
Size-Length	8.75 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The OP484FSZ is a Quad 4MHz Bandwidth Operational Amplifier features rail-to-rail inputs and outputs. This amplifier is superb for single-supply applications requiring both AC and precision DC performance. The combination of wide bandwidth, low noise and precision makes the OP484 useful in a wide variety of applications, including filters and instrumentation. Other applications include portable telecommunications equipment, power supply control and protection and use as amplifiers or buffers for transducers with wide output ranges. Sensors requiring a rail-to-rail input amplifier include Hall Effect, piezoelectric and resistive transducers. The ability to swing rail-to-rail at both the input and output enables designers to build multistage filters in single-supply systems and to maintain high signal-to-noise ratios.
Single-supply operation
Wide bandwidth
Low offset voltage (65µV)
Unity gain stable
High slew rate
Low noise (3.9nV/√Hz)
ESD sensitive device, take proper precaution while handling the device.
