OPA1644AID - TI
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoOPA1644AID
-
ManufacturerTI
-
ChipWorker Part#CW8414450
-
CategoryOperational Amplifier, OP Amp IC
-
PackageSOIC-14
-
DescriptionTEXAS INSTRUMENTS OPA1644AID Operational Amplifier, Quad, 4 Amplifier, 11MHz, 20V/µs, ± 2.25V to ± 18V, SOIC, 14Pins
-
DocumentationDatasheet
Payment Methods and Delivery
{{ estimate }}
OPA1644AID Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
- |
{{outStock}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
- | ${{UpToFourDecimals(priceCalc,skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
{{ apiText }}{{ apiTime }}(UTC+8)
OPA1644AID Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | OPA1644AID |
| Manufacturer | TI |
| ChipWorker Part# | CW8414450 |
| Category | Operational Amplifier, OP Amp IC |
| Documentation | Datasheet |
| Mounting Style | Surface Mount |
| Number of Pins | 14 Pin |
| Case/Package | SOIC-14 |
| Supply Current | 1.8 mA |
| Number of Circuits | 4 Circuit |
| Number of Channels | 4 Channel |
| Number of Positions | 14 Position |
| Common Mode Rejection Ratio | 120 dB |
| Input Offset Drift | 0.00 V/K |
| Bandwidth | 11 MHz |
| Slew Rate | 20.0 V/μs |
| Gain Bandwidth Product | 11 MHz |
| Input Offset Voltage | 1 mV |
| Input Bias Current | 2 pA |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Gain Bandwidth | 11 MHz |
| Minimum CMRR Range | 120 dB |
| Supply Voltage (Max) | 18 V |
| Supply Voltage (Min) | 2.25 V |
| expand all | |
| Size-Length | 8.75 mm |
| Size-Width | 4 mm |
| Size-Height | 1.5 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Each |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
Product Description
- The OPA1644AID is a quad JFET-input ultralow distortion low-noise Operational Amplifier for use with broadcast studio equipment. The rail-to-rail output swing allows increased headroom, making this device ideal for use in any audio circuit. Features include 5.1nV/√Hz noise, low THD+N (0.00005%), a low input bias current of 2pA and low quiescent current of 1.8mA per channel. This device operates over a very wide supply voltage range of ±2.25 to ±18V. The operational amplifier is unity-gain stable and provide excellent dynamic behaviour over a wide range of load conditions. The quad version features completely independent circuitry for lowest crosstalk and freedom from interactions between channels, even when overdriven or overloaded.
- Superior sound quality
- Unity gain stable
- No phase reversal
- Rail-to-rail output
- 126dB Typical CMRR
- Green product and no Sb/Br
