P6SMB39AT3G ,TVS Diode - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

96 points

Part No

P6SMB39AT3G
Manufacturer

ON Semiconductor
ChipWorker Part#

CW75083741
Category

TVS Diode
Package

SMB
Description

SMB 33.3V 600W
Documentation

Datasheet
Ships from

Moscow
Наличие

242166 pcs In Stock
Estimated Price

$ 0.05

Buy P6SMB39AT3G

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

P6SMB39AT3G Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

P6SMB39AT3G Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	P6SMB39AT3G
Manufacturer	ON Semiconductor
ChipWorker Part#	CW75083741
Category	TVS Diode
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	SMB
Voltage Rating (DC)	39.0 V
Operating Voltage	33.3 V
Current Rating	11.2 A
Capacitance	500 pF
Power Rating	600 W
Breakdown Voltage	37.1 V
Number of Circuits	1 Circuit
Number of Positions	2 Position
Power Dissipation	600 W
Clamping Voltage	53.9 V
Max Repetitive Reverse Voltage (Vrrm)	33.3V
Test Current	1 mA
Max Breakdown Voltage	41 V
Peak Pulse Power	600 W
Min Breakdown Voltage	37.1 V
Reverse Breakdown Voltage	37.1 V
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature	-65℃ ~ 150℃
	expand all
Size-Length	4.6 mm
Size-Width	3.56 mm
Size-Height	2.2 mm
Operating Temperature	-65℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The P6SMB series unidirectional Zener Transient Voltage Suppressor Diode designed to protect voltage sensitive components from high voltage and high energy transients. It has excellent clamping capability, high surge capability, low Zener impedance and fast response time.
5.8 to 171V Working peak reverse voltage range
600W @ 1ms Peak power
ESD rating of Class 3 (>16kV) per human body model
Maximum clamp voltage @ peak pulse current
<5µA above 10V Low leakage current
6.8 to 200V Standard Zener breakdown voltage range
<1ns Response time
-65 to 150°C Operating temperature range
