PS2802-4-A ,Optocoupler, Optoisolator - California Eastern Laboratories

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

41 points

Part No

PS2802-4-A
Manufacturer

California Eastern Laboratories
ChipWorker Part#

CW61643467
Category

Optocoupler, Optoisolator
Package

SSOP-16
Description

Darlington Optocoupler 16Pin SMT 4Channel
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 1.95

Buy PS2802-4-A

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

PS2802-4-A Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

PS2802-4-A Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	PS2802-4-A
Manufacturer	California Eastern Laboratories
ChipWorker Part#	CW61643467
Category	Optocoupler, Optoisolator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SSOP-16
Rise/Fall Time	200 µs
Input Voltage (DC)	1.10 V
Output Voltage	≤40.0 V
Number of Circuits	4 Circuit
Number of Channels	4 Channel
Forward Voltage	1.1 V
Power Dissipation	120/chmW
Rise Time	200 µs
Isolation Voltage	2500 Vrms
Forward Current	50 mA
Output Voltage (Max)	40 V
Reverse Breakdown Voltage	6 V
Maximum Forward Voltage (Max)	1.4 V
Forward Current (Max)	50 mA
Fall Time	200 µs
Operating Temperature (Max)	100 ℃
Operating Temperature (Min)	-55 ℃
	expand all
Operating Temperature	-55℃ ~ 100℃
Product Lifecycle Status	Discontinued at Digi-Key
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

PS2501-4

California Eastern Laboratories

0.47 $/шт.

PS2806-1

California Eastern Laboratories

1032 шт.

PS2801-1-P-A

California Eastern Laboratories

0.91 $/шт.

Product Description

DESCRIPTION
The PS2802-1 and PS2802-4 are optically coupled isolators containing a GaAs light emitting diode and an NPN silicon darlington-connected photo transistor in a plastic SOP for high densityapplications. This package has shield effectto cut off ambient light.
FEATURES
• High isolation voltage (BV =2 500 Vr.m.s.)
• Small and thin package (4,16-pin SOP, Pin pitch 1.27 mm)
• High current transfer ratio (CTR=2 000 % TYP. @ IF= 1 mA, VCE= 2V)
• Ordering number of tape product: PS2802-1-F3, F4, PS2802-4-F3, F4
• Safetystandards: PS2802-1, -4
• UL approved: File No. E72422 (S)
• BSI approved: No. 8188, 8189
• VDE0884 approved (Option): PS2802-4 only
APPLICATIONS
• Programmable logic controllers
• Measuring instruments
• Hybrid IC
