PX0686 Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | PX0686 |
| Manufacturer | Bulgin Components |
| ChipWorker Part# | CW2938250 |
| Category | Power Entry Module |
| Documentation | Datasheet |
| Mounting Style | Screw |
| Number of Contacts | 3 Contact |
| Gender | Male |
| Contact Plating | Nickel |
| Voltage Rating (DC) | 250 V |
| Voltage Rating (AC) | 250 V |
| Current Rating | 10 A |
| Insulation Resistance | 10000 MΩ |
| Orientation | Straight |
| Flammability Rating | UL 94 V-0 |
| Number of Positions | 3 Position |
| Contact Resistance | 10.0 mΩ |
| Current Rating (Max) | 10 A |
| Operating Temperature (Max) | 70 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Voltage Rating (Max) | 250 VAC |
| Voltage Rating | 250 VAC |
| Maximum Contact Resistance (Max) | 10 mΩ |
| expand all | |
| Size-Length | 29 mm |
| Size-Width | 78.6 mm |
| Size-Height | 22.6 mm |
| Color | Black |
| Contact Material | Brass |
| Operating Temperature | -40℃ ~ 70℃ |
| Housing Material | Nylon |
| Product Lifecycle Status | Active |
| Packaging | Bulk |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
| HTS Code | 8536694050 |
| ECCN Code | EAR99 |
Product Description
- The PX0686 from Bulgin is a rewirable IEC power outlet with cable mounting. This EN60320-2-2 standard sheet E IEC outlet connector has electrical rating up to 10A, 250VAC offer solutions to most mains powered equipment and cable applications. Conforms to IEC and EN 60320 specifications carrying UL, CSA, VDE approvals. It mates with PX0675, PX0695, PX0578, PX0783, PX0793, PX0793/1, PX0716, PX0717, PX0718 series Bulgin connectors.
- Straight male connector
- Screw terminals
- Black colour IEC outlet
- Contact resistance is 10mohm
- Brass with nickel plated contacts
- Operating temperature range from -40°C to 70°C
- AC breakdown voltage is 5KV (pole to pole) and 5KV (poles to panel)
