SLA7026M - Sanken Electric

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

SLA7026M
Manufacturer

Sanken Electric
ChipWorker Part#

CW5920563
Category

Motor Driver
Package

SIP-18
Description

Motor Driver/Controller, Stepper, 10V to 44V supply, 100V/3A/4Outputs, SIP-18
Documentation

Datasheet

SLA7026M Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

SLA7026M Specifications

Attribute	Attribute Value

Part Number	SLA7026M
Manufacturer	Sanken Electric
ChipWorker Part#	CW5920563
Category	Motor Driver
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	18 Pin
Case/Package	SIP-18
Supply Voltage (DC)	44.0V (max)
Number of Outputs	4 Output
Output Voltage	100 V
Output Current	3 A
Number of Positions	18 Position
Power Dissipation	35000 mW
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-20 ℃
Power Dissipation (Max)	35000 mW
Supply Voltage	10V ~ 44V
Supply Voltage (Max)	44 V
Supply Voltage (Min)	10 V
	expand all
Product Lifecycle Status	Active
Packaging	Each
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

The SLA7026M is a high-current PWM unipolar stepper Motor Controller/Driver IC. An automated, innovative packaging technology combined with power FETs and monolithic logic/control circuitry advances power multi-chip modules (PMCM) toward the complete integration of motion control. Highly automated manufacturing techniques provide low-cost and exceptionally reliable PMCMs suitable for controlling and directly driving a broad range of 2-phase, unipolar stepper motors. The three stepper motor multi-chip modules differ primarily in output current ratings (1.5 or 3.0A) and package style. All three PMCMs are rated for an absolute maximum limit of 46V and utilize advanced NMOS FETs for the high-current, high-voltage driver outputs. The avalanche-rated (>=100V) FETs provide excellent ON resistance, improved body diodes and very-fast switching.
