SN65C3243DBR - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

SN65C3243DBR
Manufacturer

TI
ChipWorker Part#

CW14026415
Category

Interface IC, Interface Controller
Package

SSOP-28
Description

3V To 5.5V Multichannel RS-232 Line Driver/Receiver 28-SSOP -40℃ to 85℃
Documentation

Datasheet

SN65C3243DBR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

SN65C3243DBR Specifications

Attribute	Attribute Value

Part Number	SN65C3243DBR
Manufacturer	TI
ChipWorker Part#	CW14026415
Category	Interface IC, Interface Controller
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	28 Pin
Case/Package	SSOP-28
Supply Voltage (DC)	3.30 V, 5.00 V
Supply Current	1 mA
Number of Positions	28 Position
Data Rate	1.00 Mbps
Drivers Per Package	3
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	10.5 mm
Size-Width	5.6 mm
Size-Height	1.95 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

The SN65C3243DBR is a RS-232 multichannel Line Driver/Receiver consist of three line drivers, five line receivers and a dual charge-pump circuit. It has ±15kV ESD protection pin-to-pin (serial-port connection pins, including GND). This device provides the electrical interface between an asynchronous communication controller and the serial-port connector. The charge pump and four small external capacitors allow operation from a single 3 to 5.5V supply. In addition, this device includes an always-active non-inverting output (ROUT2B), which allows applications using the ring indicator to transmit data while the device is powered down. The device operates at data signalling rates up to 1Mbps and an increased slew-rate range of 24 to 150V/µs. Flexible control options for power management are available when the serial port is inactive. The auto-power-down feature functions when FORCEON is low and FORCEOFF is high.
