SN75ALS181NSR - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

SN75ALS181NSR
Manufacturer

TI
ChipWorker Part#

CW37349665
Category

Interface IC, Interface Controller
Package

SOIC-14
Description

Transceiver, RS422 / RS485, 1 Driver, 4.75V to 5.25V, SOIC-14
Documentation

Datasheet

SN75ALS181NSR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

SN75ALS181NSR Specifications

Attribute	Attribute Value

Part Number	SN75ALS181NSR
Manufacturer	TI
ChipWorker Part#	CW37349665
Category	Interface IC, Interface Controller
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SOIC-14
Supply Voltage (DC)	4.75V (min)
Supply Current	30 mA
Number of Positions	14 Position
Drivers Per Package	1
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage	4.75V ~ 5.25V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	4.75 V
	expand all
Size-Length	10.3 mm
Size-Width	5.3 mm
Size-Height	1.95 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Product Description

The SN75ALS181NSR is a Differential Driver and Receiver designed for bidirectional data communication on multipoint bus transmission lines. The design provides for balanced transmission lines and meets TIA/EIA-422-B and TIA/EIA-485-A, CCITT recommendations V.10, V.11, X.26 and X.27. It combines a 3-state differential line driver and a differential-input line receiver that operate from a single 5V power supply. The driver and receiver have active-high and active-low enables, respectively, that can be connected together externally to function as a direction control. The driver differential outputs and the receiver differential inputs are connected to separate pins for greater flexibility and are designed to offer minimum loading to the bus when the driver is disabled or VCC=0. These ports feature wide positive and negative common-mode voltage changes, making the device suitable for party-line applications.
Thermal shutdown protection
Glitch-free power-up and power-down protection
30mA Maximum low supply-current
±60mA Driver output capacity
-7 to 12V Driver common-mode output voltage range
12kR Minimum receiver input impedance
±200mV Receiver input sensitivity
60mV Typical receiver input hysteresis
±12V Receiver common-mode input voltage
Green product and no Sb/Br
