Part No

STMPS2151STR
Manufacturer

ST Microelectronics
ChipWorker Part#

CW229083
Category

Power Distribution
Package

SOT-23-5
Description

Current Limit SW 1IN 1Out 2.7V to 5.5V 0.5A 5Pin SOT-23 T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

9537 pcs In Stock
Estimated Price

$ 0.34

Buy STMPS2151STR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

STMPS2151STR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

STMPS2151STR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	STMPS2151STR
Manufacturer	ST Microelectronics
ChipWorker Part#	CW229083
Category	Power Distribution
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	5 Pin
Case/Package	SOT-23-5
Operating Voltage	5.50V (max)
Number of Outputs	1 Output
Input Voltage (DC)	5.00 V
Output Current	0.5 A
Supply Current	0.04 mA
Number of Positions	5 Position
Power Dissipation	0.0325 W
Rise Time	2 ms
Input Voltage (Max)	5.5 V
Input Voltage (Min)	2.7 V
Output Current (Max)	500 mA
Number of Inputs	1 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	33.8 mW
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
Input Voltage	5 V
	expand all
Size-Length	3 mm
Size-Width	1.75 mm
Size-Height	1.3 mm
Operating Temperature	-40℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The STMPS2151STR is a Power Distribution Switch is intended for applications where heavy capacitive loads and short-circuits are likely to be encountered. This device incorporates 90mR N-channel MOSFET high-side power switches for power distribution. This switch is controlled by a logic enable input. When the output load exceeds the current limit threshold or a short is present, the device limits the output current to a safe level by switching into a constant current mode. When continuous heavy overloads and short-circuits increase the power dissipation in the switch, causing the junction temperature to rise, a thermal protection circuit shuts the switch off to prevent damage.
500/1000mA Continuous current
2.7 to 5.5V Operating range
CMOS and TTL compatible enable input
Under voltage lockout (UVLO)
12µA Maximum standby supply current
8kV ESD protection
Reverse current protection
Fault blanking
