Part No

STN1NF20
Manufacturer

ST Microelectronics
ChipWorker Part#

CW20436400
Category

MOSFET, MOSFET Transistor
Package

TO-261-4
Description

Trans MOSFET N-CH 200V 1A 4Pin(3+Tab) SOT-223 T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.57
