TLD5095EL - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TLD5095EL
Manufacturer

Infineon
ChipWorker Part#

CW95184732
Category

LED Driver
Package

SSOP-14
Description

LED DRVR 5V/9V/12V/15V/18V/24V 14Pin SSOP EP
Documentation

Datasheet

TLD5095EL Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TLD5095EL Specifications

Attribute	Attribute Value

Part Number	TLD5095EL
Manufacturer	Infineon
ChipWorker Part#	CW95184732
Category	LED Driver
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SSOP-14
Frequency	100kHz ~ 500kHz
Number of Outputs	1 Output
Output Voltage	4.6V ~ 5.4V
Supply Voltage	4.75V ~ 45V
	expand all
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

Description:
The TLD5095EL is a LED boost controller with built in protection features. The controller concept of the TLD5095EL allows multiple configurations such as Boost, Buck, Buck-Boost, SEPIC and Flyback by simply adjusting the external components. TLD5095EL is the simplest member of the TLD509x series and comes with reduced maximum output voltage of 45V, less current accuracy and is missing the analog dimming feature as well as a short to ground protection.
Summary of Features:
Single-Channel Multitopology (B2B, B2G, SEPIC, Flyback) DC/DC Controller
Constant Current or Constant Voltage Regulation
Wide Input Voltage Range from 4.75 V to 45 V
Very Low Shutdown Current: IQ< 10 μA
Switching Frequency Range from 100 kHz to 500 kHz
Synchronization with external clock source
Output Open Circuit Diagnostic Output
PWM Dimming
Internal Soft Start
300mV High Side Current Sense to ensure highest flexibility and LED current accuracy
Internal 5 V Low Drop Out Voltage Regulator
Wide LED current range via simple adaptation of external components
Output Overvoltage Protection
Over Temperature Shutdown
Available in a small thermally enhanced PG-SSOP-14 package
Automotive AEC Qualified
