XB4BVM4 - Schneider Electric

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

XB4BVM4
Manufacturer

Schneider Electric
ChipWorker Part#

CW17126368
Category

Pushbutton Switch, Switch Push button
Description

SCHNEIDER ELECTRIC XB4BVM4 LED Panel Mount Indicator, Red, 240VAC, 22mm, IP66, NEMA 4X, NEMA 13 New
Documentation

Datasheet

XB4BVM4 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

XB4BVM4 Specifications

Attribute	Attribute Value

Part Number	XB4BVM4
Manufacturer	Schneider Electric
ChipWorker Part#	CW17126368
Category	Pushbutton Switch, Switch Push button
Documentation	Datasheet
Mounting Style	Panel
Operating Voltage	240 VAC
Voltage Rating	240 VAC
Supply Voltage	230.240 VAC
	expand all
Color	Red
Operating Temperature	-25℃ ~ 70℃
Packaging	Each
RoHS	RoHS Compliant
REACH SVHC Compliance Edition	2015/12/17

Product Description

The XB4BVM4 from Schneider Electric is a Harmony XB4 red colour complete pilot light plain lens with integral protected LED. It has round shape signalling unit head. The device also has IP66 degree of protection conforming to IEC 60529, IK05 degree of protection conforming to IEC 50102, NEMA 4X and NEMA 13 degree of protection. It complies with CSA C22-2 number 14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, EN/IEC 60947-5-5, JIS C 4520 and UL 508 standards.
Rated supply voltage from 230VAC to 240VAC, 50Hz/60Hz
Screw clamp terminal connections
Mounting diameter of 22mm
Chromium plated metal bezel material and zamak fixing collar material
Dimension is 47mm x 30mm x 54mm (H x W x D)
Rated insulation voltage of 250V conforming to EN 60947-1
Rated impulse withstand voltage of 4KV conforming to EN 60947-1
Current consumption of 14mA
Service life of 100000h at rated voltage and 25°C
Ambient air temperature for operation from -25°C to 70°C
