TLP283 - Toshiba

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TLP283
Manufacturer

Toshiba
ChipWorker Part#

CW82677650
Category

Optocoupler, Optoisolator
Package

SOP-4
Description

Optocoupler DC-IN 1CH Transistor DC-OUT 4Pin SOP
Documentation

Datasheet

TLP283 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TLP283 Specifications

Attribute	Attribute Value

Part Number	TLP283
Manufacturer	Toshiba
ChipWorker Part#	CW82677650
Category	Optocoupler, Optoisolator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	4 Pin
Case/Package	SOP-4
Input Voltage (DC)	1.15 V
Output Voltage	≤100 V
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Forward Voltage	1.15 V
Power Dissipation	200 mW
Rise Time	7.50 µs
Isolation Voltage	2500 Vrms
Output Voltage (Max)	100 V
Maximum Forward Voltage (Max)	1.3 V
Forward Current (Max)	50 mA
Operating Temperature (Max)	100 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	200 mW
	expand all
Size-Height	1.9 mm
Product Lifecycle Status	Obsolete
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead

Product Description

PROGRAMMABLE CONTROLLERS
AC adapters for PDAs/ on-board power supplies
I/O interface boards
TLP283 and TLP283-4 is a very small and thin coupler,suitable for surface mount assembly in applications such as on-board power supplies,programmable controllers. TLP283 and TLP283-4 consist of photo transistor,optically coupled to a gallium arsenide infrared emitting diode.
Collector-Emitter Voltage : 100 V (MIN)
Current Transfer Ratio : 100% (MIN)@IF=1mA
1 Pulse delay time(Note 1) : 100us(MAX)@IF=1mA,RL=10kΩ
Isolation Voltage : 2500 Vrms (MIN)
UL Recognized : UL1577 , File No. E67349
Note 1 : 1 Pulse delay time = tON+tOFF
