TLV27L1IDBVR ,Operational Amplifier, OP Amp IC - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

165 points

Part No

TLV27L1IDBVR
Manufacturer

TI
ChipWorker Part#

CW11943896
Category

Operational Amplifier, OP Amp IC
Package

SOT-23-5
Description

TEXAS INSTRUMENTS TLV27L1IDBVR Operational Amplifier, Single, 1 Amplifier, 160kHz, 0.06V/µs, 2.7V to 16V, SOT-23, 5Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

1476 pcs In Stock
Estimated Price

$ 0.48

Buy TLV27L1IDBVR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TLV27L1IDBVR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TLV27L1IDBVR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TLV27L1IDBVR
Manufacturer	TI
ChipWorker Part#	CW11943896
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	5 Pin
Case/Package	SOT-23-5
Output Current	0.4mA @2.7V
Supply Current	7 µA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	5 Position
Power Dissipation	0.385 W
Common Mode Rejection Ratio	71 dB
Input Offset Drift	1.10 µV/K
Bandwidth	160 kHz
Slew Rate	60.0 mV/μs
Gain Bandwidth Product	160 kHz
Input Offset Voltage	500 µV
Input Bias Current	1 pA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	160 kHz
Power Dissipation (Max)	385 mW
Minimum CMRR Range	71 dB
Supply Voltage	2.7V ~ 16V
Supply Voltage (Max)	16 V
Supply Voltage (Min)	2.7 V
	expand all
Size-Length	2.9 mm
Size-Width	1.6 mm
Size-Height	1.3 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
HK STC License	NLR

Similar & Replacement Parts

Similar products

Product Description

DESCRIPTION
The TLV27Lx single supply operational amplifiers provide rail-to-rail output capability. The TLV27Lx takes
the minimum operating supply voltage down to 2.7 V over the extended industrial temperature range, while adding the rail-to-rail output swing feature. The TLV27Lx also provides 160-kHz bandwidth from only 7µA. The maximum recommended supply voltage is 16 V, which allows the devices to be operated from (±8-V supplies down to ±1.35 V) two rechargeable cells.
FEATURES
BiMOS Rail-to-Rail Output
Input Bias Current...1 pA
High Wide Bandwidth...160 kHz
High Slew Rate...0.1 V/µs
Supply Current...7 µA (per channel)
Input Noise Voltage ...89 nV/√Hz
Supply Voltage Range...2.7 V to 16 V
Specified Temperature Range
– –40°C to 125°C...Industrial Grade
– 0°C to 70°C...Commercial Grade
Ultra-Small Packaging
– 5 Pin SOT-23 (TLV27L1)
APPLICATIONS
Portable Medical
Power Monitoring
Low Power Security Detection Systems
Smoke Detectors
