TPS2812D ,FET Driver - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

116 points

Part No

TPS2812D
Manufacturer

TI
ChipWorker Part#

CW10008196
Category

FET Driver
Package

SOIC-8
Description

MOSFET DRVR 2A 2Out High Speed Non-Inv 8Pin SOIC Tube
Documentation

Datasheet
Ships from

Moscow
Наличие

1740 pcs In Stock
Estimated Price

$ 2.04

Buy TPS2812D
