TPS74701DRCT - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TPS74701DRCT
Manufacturer

TI
ChipWorker Part#

CW20758696
Category

Voltage Regulator
Package

VSON-10
Description

TEXAS INSTRUMENTS TPS74701DRCT LDO Voltage Regulator, Adjustable, 800mV to 5.5V in, 50mV drop, 800mV to 3.6V/0.5A out, SON-10
Documentation

Datasheet

TPS74701DRCT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TPS74701DRCT Specifications

Attribute	Attribute Value

Part Number	TPS74701DRCT
Manufacturer	TI
ChipWorker Part#	CW20758696
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	VSON-10
Number of Outputs	1 Output
Output Voltage	0.8V ~ 3.6V
Output Current	500 mA
Number of Positions	10 Position
Power Dissipation	1920 W
Quiescent Current	1.00 mA
Output Capacitor Type	Ceramic
voltage rating	0.05V @500mA
Number of Regulated Outputs	1 Output
Input Voltage (Max)	5.5 V
Input Voltage (Min)	0.8 V
Output Voltage (Max)	3.6 V
Output Voltage (Min)	800 mV
Output Current (Max)	0.5 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Accuracy	±0.5 %
Input Voltage	0.8V ~ 5.5V
	expand all
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.9 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Product Description

The TPS74701DRCT is a low-dropout (LDO) Linear Regulator provides an easy-to-use, robust power management solution for a wide variety of applications. User-programmable soft-start minimizes stress on the input power source by reducing capacitive inrush current on start-up. The soft-start is monotonic and well-suited for powering many different types of processors and ASICs. The enable input and power good output allow easy sequencing with external regulator. This complete flexibility permits the user to configure a solution that meets the sequencing requirements of FPGAs, DSPs and other applications with special start-up requirements. A precision reference and error amplifier deliver 2% accuracy over load, line, temperature and process. It features soft-start capability. This regulator uses a low current bias input to power all internal control circuitry, allowing the NMOS pass transistor to regulate very low input and output voltages.
Power good (PG) output allows supply monitoring or provides a sequencing signal for other supplies
VBIAS permits low VIN operation with good transient response
Stable with >=2.2µF any output capacitor
50mV Typically at 500mA, VBIAS = 5V low dropout
Green product and no Sb/Br
