TS1851IDT ,Operational Amplifier, OP Amp IC - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

89 points

Part No

TS1851IDT
Manufacturer

ST Microelectronics
ChipWorker Part#

CW104022215
Category

Operational Amplifier, OP Amp IC
Package

SO-8
Description

**1xOP 530kHz 0,18V/µs SO8 _SMD **
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.07

Buy TS1851IDT

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TS1851IDT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TS1851IDT Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TS1851IDT
Manufacturer	ST Microelectronics
ChipWorker Part#	CW104022215
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SO-8
Output Current	48mA @5V
Supply Current	162 µA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Slew Rate	180 mV/μs
Gain Bandwidth Product	0.656 MHz
Input Offset Voltage	1 mV
Input Bias Current	16 nA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	0.656 MHz
Minimum CMRR Range	65 dB
Supply Voltage	1.8V ~ 6V
Supply Voltage (Max)	6V ~ 9V
	expand all
Size-Height	1.65 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

**Description**
The TS185x (single, dual and quad) can operate with voltages as low as 1.8 V. They feature both input and output rail-to-rail (1.71 at VCC = 1.8 V,RL = 2 kΩ), 120 μA current consumption and 530 kHz gain bandwidth product. With this low consumption and a sufficient GBP for many applications, these operational amplifiers are well-suited to all kinds of battery supplied and portable applications.
The TS1851 is housed in the space-saving 5-pin SOT23-5 package, which simplifies board design
(outside dimensions are 2.8 mm x 2.9 mm).
**Features**
■ Operating range from VCC = 1.8 to 6 V
■ Rail-to-rail input and output
■ Extended Vicm (VCC- \- 0.2 V to VCC + \+ 0.2 V)
■ Low supply current (120 μA)
■ Good accuracy (1 mV max for A version)
■ Gain bandwidth product (530 kHz)
■ High unity gain stability (able to drive 500 pF)
■ ESD tolerance (2 kV)
■ Latch-up immunity
■ Available in SOT23-5 micropackage
**Applications**
■ Two-cell battery-powered systems
■ Battery-powered electronic equipment
■ Cordless phones
■ Cellular phones
■ Laptops
■ PDAs
