AM26LV32EIDR - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AM26LV32EIDR
Manufacturer

TI
ChipWorker Part#

CW6276734
Category

Interface IC, Interface Controller
Package

SOIC-16
Description

Low-Voltage High-Speed Quadruple Differential Line Receiver With +/-15kV IEC ESD 16-SOIC -40℃ to 85℃
Documentation

Datasheet

AM26LV32EIDR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AM26LV32EIDR Specifications

Attribute	Attribute Value

Part Number	AM26LV32EIDR
Manufacturer	TI
ChipWorker Part#	CW6276734
Category	Interface IC, Interface Controller
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Current	17 mA
Number of Positions	16 Position
Power Dissipation	27 mW
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	27 mW
Supply Voltage	3V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	3 V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

The AM26LV32EIDR is a quadruple differential Line Receiver with 3-state outputs. This device is designed to meet TIA/EIA-422-B and ITU recommendation V.11 drivers with reduced supply voltage. The device is optimized for balanced bus transmission at switching rates up to 32MHz. The 3-state outputs permit connection directly to a bus-organized system. The AM26LV32E has an internal fail-safe circuitry that prevents the device from putting an unknown voltage signal at the receiver outputs. In the open fail-safe, shorted fail-safe and terminated fail-safe, a high state is produced at the respective output. This receiver is supported for partial-power-down applications using Ioff. Ioff circuitry disables the outputs, preventing damaging current back-flow through the device when it is powered down.
Meets or exceeds standards TIA/EIA-422-B and ITU recommendation V.11
ESD protection for RS422 bus pins
IOFF supports partial power-down-mode operation
27mW Typical low power dissipation
Open circuit, short-circuit and terminated fail-safe
35mV Typical input hysteresis
Green product and no Sb/Br
This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
