TS462CPT - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TS462CPT
Manufacturer

ST Microelectronics
ChipWorker Part#

CW26911882
Category

Amplifier, Buffer IC
Package

TSSOP-8
Description

**2xOP 12MHz 4V/µs TSSOP8 _SMD **
Documentation

Datasheet

TS462CPT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TS462CPT Specifications

Attribute	Attribute Value

Part Number	TS462CPT
Manufacturer	ST Microelectronics
ChipWorker Part#	CW26911882
Category	Amplifier, Buffer IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	TSSOP-8
Supply Current	2 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Common Mode Rejection Ratio	60 dB
Slew Rate	4.00 V/μs
Gain Bandwidth Product	12 MHz
Input Offset Voltage	1 mV
Input Bias Current	200 nA
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	-20 ℃
Gain Bandwidth	12 MHz
Minimum CMRR Range	60 dB
Supply Voltage	2.7V ~ 10V
Supply Voltage (Max)	10 V
Supply Voltage (Min)	2.7 V
	expand all
Size-Width	4.4 mm
Size-Height	1 mm
Operating Temperature	-20℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

Description
The TS46x are a family of operational amplifiers able to operate with voltages as low as ±1.35V
and to reach a minimum of ±2Vppof output swing when supplied with ±2.5V.
This device is well-suited for all kinds of portable and battery-supplied equipment, where low noise
and low distortion are key requirements.
The TS461/2/4 offer excellent output rail-to-rail performance at an attractive cost.
■ High dynamic features
■ Large output swing (±2.4V @ VCC= ±2.5V)
■ Low noise level: 4nV/√Hz
■ Low distortion: 0.003%
■ Operating range: 2.7V to 10V
■ Available in SOT23-5 micropackage
Applications
■ Sound cards
■ PDA
■ CD players
■ Recording equipment
■ Multimedia
■ Microphone preamplifiers
