Part No

UC1525A
Manufacturer

TI
ChipWorker Part#

CW392907465
Package

CDIP-16
Description

The UC1525A/1527A series of pulse width modulator integrated circuits are designed to offer improved performance and lowered external parts count when used in designing all types of switching power supplies
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

Price on Request

Buy UC1525A
