14-354000-11-RC ,IC Socket - Aries Electronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

42 points

Part No

14-354000-11-RC
Manufacturer

Aries Electronics
ChipWorker Part#

CW61989564
Category

IC Socket
Description

ARIES 14-354000-11-RC IC & Component Socket, 354000 Series, Adaptor, 14Contacts, 1.27mm, 7.62mm, Gold Plated Contacts
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 25.79

Buy 14-354000-11-RC

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

14-354000-11-RC Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

14-354000-11-RC Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	14-354000-11-RC
Manufacturer	Aries Electronics
ChipWorker Part#	CW61989564
Category	IC Socket
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	14 Pin
Number of Contacts	14 Contact
Contact Plating	Gold
Current Rating	3 A
Flammability Rating	UL 94 V-0
	expand all
Contact Material	Beryllium Copper
Material	Polyester
Product Lifecycle Status	Active
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The 354000 series from Aries are 2.54mm pitch DIP to SOIC adapters. It is a convenient, cost effective means of converting DIP style packaging to SOIC PC board layouts.
Available with 8, 14, 16, 20, 24, 28 contacts
Socket body is black, UL94 V-0 glass-filled 4/6 nylon 170°C continuous use temperature
PCB is.062 thick FR406 OR IS410 per IPC4101A/26 with 1oz copper traces
Male adapter pin is brass alloy with gold plating
Female contact pin is brass alloy with gold plating
4-fingered collet contact is beryllium copper alloy per UNS C17200 ASTM-B194-01
Contact current rating is 3A
Operating temperature is 221°F
Socket accepts leads.015 to.025inch [.38mm-.64mm] in diameter,.100-.125inch [2.54mm-3.18mm] long
Suggested PCB solder pad size of 0.028inch (0.71mm) min width

expand all
