1729021 - Phoenix

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

1729021
Manufacturer

Phoenix
ChipWorker Part#

CW38335148
Category

Terminal Block, Connector Terminal
Package

-
Description

Conn PC Terminal Block 3POS 5mm Solder ST Thru-Hole 13.5A
Documentation

Datasheet

1729021 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

1729021 Specifications

Attribute	Attribute Value

Part Number	1729021
Manufacturer	Phoenix
ChipWorker Part#	CW38335148
Category	Terminal Block, Connector Terminal
Documentation	Datasheet
Mounting Style	Through Hole
Case/Package	-
Pin Pitch	5 mm
Number of Contacts	3 Contact
Wire Gauge	14AWG ~ 30AWG
Current Rating	13.5 A
Number of Rows	1 Row
Number of Circuits	3 Circuit
Flammability Rating	UL 94 V-0
Number of Positions	3 Position
Current Rating (Max)	13.5 A
Voltage Rating (Max)	250 V
Voltage Rating	400 V
Operating Voltage (Max)	400 V
	expand all
Size-Length	8.1 mm
Size-Width	10 mm
Size-Height	10 mm
Housing Color	Green
Color	Green
Material	Polyamide (PA)
Insulation Material	Nylon
Housing Material	Nylon
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
HTS Code	8536904000
ECCN Code	EAR99

Product Description

Screw Connection, Soldering Type Mounting, Printed Circuit Terminal Block
* The hole diameter is 1.3 mm
* Polyamide Insulating Material
* Voltage: 300, Amps:10, AWG: 30-14
* Screw Connection Blocks
