2814744 Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | 2814744 | |
| Manufacturer | Phoenix | |
| ChipWorker Part# | CW56024176 | |
| Category | Sensor | |
| Documentation | Datasheet | |
| Mounting Style | Screw | |
| Case/Package | Module | |
| Frequency | 15Hz ~ 400Hz | |
| Current Rating | 55 A | |
| Number of Channels | 1 Channel | |
| Input Current | 0A ~ 11A | |
| Output Voltage (Max) | 10 V | |
| Operating Temperature (Max) | 60 ℃ | |
| Operating Temperature (Min) | -20 ℃ | |
| Accuracy | ±0.5 % | |
| Voltage Rating | 20 V | |
| Supply Voltage | 20VDC ~ 30VDC | |
| expand all | ||
| Size-Length | 3.9 in | |
| Size-Width | 22.5 mm | |
| Size-Height | 4.5 in | |
| Color | Green | |
| Operating Temperature | -20℃ ~ 60℃ | |
| Product Lifecycle Status | Active | |
| Packaging | Bulk | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free | |
| HTS Code | 8543704000 | |
| ECCN Code | EAR99 |
Similar & Replacement Parts
Similar products
Product Description
- MCR Current Measuring Transducer, 20 to 30 VDC Supply Voltage
- * Polyamide PA non-reinforced housing
- * Green color
- MCR current measuring transducer, programmable and configurable, for measuring direct, alternating and distorted currents, with relay and transistor output, input.
