2866789 ,AC to DC Converter, AC/DC Converter - Phoenix
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
50 points
-
Part No2866789
-
ManufacturerPhoenix
-
ChipWorker Part#CW51695513
-
CategoryAC to DC Converter, AC/DC Converter
-
DescriptionAC-DC Power Supply Single-OUT 24V 40A 960W 12Pin
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие7 pcs In Stock
-
Estimated Price$ 940.84
Payment Methods and Delivery
{{ estimate }}
Buy 2866789
Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.
Real stock check
Best price from distributors
Engineer support
2866789 Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}xx
{{ low_stock_text }}
|
1 |
{{weeks_text}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
{{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
|
Chipworker
|
{{noList.partNo}}
{{noList.mfr}}
|
{{stockAvailability}}
{{ search_item }}
|
{{moq}} | 1 | 6 - 8 {{delivery_date}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
|||||||
{{ apiText }}{{ apiTime }}(UTC+8)
Update Data
Chipworker Certification
11+ years sourcing experience
1000+ russia customers
ISO certified supplier
Support small MOQ
*Photos of Our Actual 800 m² Warehouse
2866789 Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | 2866789 | |
| Manufacturer | Phoenix | |
| ChipWorker Part# | CW51695513 | |
| Category | AC to DC Converter, AC/DC Converter | |
| Documentation | Datasheet | |
| Mounting Style | DIN Rail | |
| Number of Pins | 12 Pin | |
| Power Rating | 960 W | |
| Number of Outputs | 1 Output | |
| Output Voltage | 24 V | |
| Output Current | 40 A | |
| Output Power | 960 W | |
| Isolation Voltage | 4 kV | |
| Input Voltage (Max) | 264 VAC | |
| Input Voltage (Min) | 85 VAC | |
| Input Voltage (DC Max) | 300 V | |
| Input Voltage (DC Min) | 120 V | |
| Input Voltage (AC Max) | 264 V | |
| Input Voltage (AC Min) | 85 V | |
| Output Voltage (Max) | 29.5 VDC | |
| Output Voltage (Min) | 18 VDC | |
| Output Current (Max) | 40 A | |
| Input Power (Max) | 960 W | |
| Operating Temperature (Max) | 70 ℃ | |
| Operating Temperature (Min) | -25 ℃ | |
| Input Voltage | 85VAC ~ 264VAC | |
| expand all | ||
| Size-Length | 180 mm | |
| Size-Width | 130 mm | |
| Size-Height | 130 mm | |
| Weight | 3.3 kg | |
| Operating Temperature | -25℃ ~ 70℃ | |
| Product Lifecycle Status | Active | |
| Packaging | Bulk | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free | |
| HTS Code | 8504407018 | |
| ECCN Code | EAR99 |
Similar & Replacement Parts
Similar products
Product Description
- The QUINT SFB is the first industrial grade power supply to feature Selective Fuse Breaking (SFB), a technology that enables standard power circuit breakers to be triggered reliably and quickly. This power supply provides up to six times nominal current for 12 ms. This short burst of current allows individual circuit breakers to react to overloads. Faulty current paths are shut down, while the power supply continues to deliver power to the other loads. The SFB technology"s power reserve is also available for loads with high start-up current peaks. This power supply also provides continual diagnostic monitoring by constantly checking the output voltage and output current. This predictive function monitoring recognizes critical operating states, visualizes and reports them to the controller in good time. This early detection warns of critical operating states before errors occur. When the power supply system is operating under nominal conditions a (DC OK) LED indicates the status on the power supply unit. During overload conditions, the (DC OK) LED will change state to indicate possible fault conditions. The power supply also has an additional LED to indicate the unit is supplying more than nominal current, when in the Power Boost mode. The Quint SFB Power supplies are an average of 30 percent narrower than standard QUINT Power Supply units. This frees space on the mounting rail for other components. A wide temperature range and international approvals make the QUINT SFB an ideal power supply for industrial applications. The QUINT-PS/1AC/24DC/20 is a 24 V DC, 20 Amp power supply unit.*Features:**
- * Selective Fuse Breaking shuts down faulty current paths while delivering power to other loads
- * The static POWER BOOST provides an dependable way to start heavy loads
- * The power supply unit visually warns of critical operating states before errors occur
- * Narrow design results in more space on the mounting rail for other components
- * 100 to 240 VAC nominal input voltage
- * DC to DC converter, AC to DC converter
- * 130mmHx125mmD
- * LED green operating voltage display
- * >93% efficiency
- * IP20 degree of protection
- * -25 to 70 °C operating temperature
- * Pluggable screw connection
- * CB, UL, cULus Recognized, CSA Certified
- * RoHS Compliant
