2904602 - Phoenix

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

2904602
Manufacturer

Phoenix
ChipWorker Part#

CW42803003
Category

AC to DC Converter, AC/DC Converter
Description

PHOENIX CONTACT 2904602 AC-DC DIN Rail Power Supply, IP20, Adjustable, Fixed, 1 Output, 85VAC, 264VAC, 480W, 24VDC
Documentation

Datasheet

2904602 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

2904602 Specifications

Attribute	Attribute Value

Part Number	2904602
Manufacturer	Phoenix
ChipWorker Part#	CW42803003
Category	AC to DC Converter, AC/DC Converter
Documentation	Datasheet
Number of Pins	15 Pin
Power Rating	480 W
Number of Outputs	1 Output
Output Voltage	24 VDC
Output Current	20 A
Power Dissipation	5000 mW
Output Power	480 W
Isolation Voltage	4 kV
Input Voltage (Max)	240 VAC
Input Voltage (Min)	85 VAC
Input Voltage (AC Max)	264 v
Input Voltage (AC Min)	85 v
Output Voltage (Max)	29.5 VDC
Output Voltage (Min)	24 VDC
Output Current (Max)	20 A
Input Current (Min)	6.8 A
Input Power (Max)	480 W
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	25 ℃
Input Voltage	85VAC ~ 264VAC
	expand all
Size-Length	125 mm
Size-Width	70 mm
Size-Height	130 mm
Weight	1.3 kg
Operating Temperature	-25℃ ~ 70℃
Product Lifecycle Status	Active
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

**QUINT Power Supply Units – Maximum system availability with SFB technology**
Compact power supply units of the new QUINT POWER generation maximize the availability of your system. With the SFB technology (Selective Fuse Breaking Technology), six times the nominal current for 12 ms, even the standard power circuit-breakers can now also be triggered reliably and quickly. Faulty current paths are switched off selectively, the fault is located and important system parts continue to operate. Comprehensive diagnostics are provided through constant monitoring of output voltage and current. This preventive function monitoring visualizes critical operating modes and reports them to the control unit before an error can occur.
**Features**
* Quick tripping of the standard power circuit-breakers using dynamic power reserve SFB technology
* Reliable starting of difficult loads with static POWER BOOST power reserve
* Preventive function monitoring
* Can be used worldwide
* High operating safety due to long mains buffering under full load and high MTBF (> 500,000 h)
* Perfect functioning even in the event of a permanent phase failure
* High surge voltage strength up to 6 kV (surge, asymmetric) using an integrated gas arrester
