2981020 - Phoenix

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

2981020
Manufacturer

Phoenix
ChipWorker Part#

CW66564140
Category

Power Relay
Description

Electromechanical Relay 24VDC 400Ω 6A (22.5x114.5x99)mm DIN Rail Safety Relay
Documentation

Datasheet

2981020 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

2981020 Specifications

Attribute	Attribute Value

Part Number	2981020
Manufacturer	Phoenix
ChipWorker Part#	CW66564140
Category	Power Relay
Documentation	Datasheet
Mounting Style	Screw
Voltage Rating (DC)	250 V
Voltage Rating (AC)	250 V
Current Rating	6 A
Number of Channels	1 Channel
Contact Current Rating	6 A
Coil Voltage	24 VDC
Coil Current	60 mA
Coil Resistance	400 Ω
Current Rating (Max)	6 A
Coil Voltage (DC)	24 V
Input Power (Max)	1.5 KVA
Operating Temperature (Max)	55 ℃
Operating Temperature (Min)	-20 ℃
Voltage Rating	250 VAC
Voltage Rating (DC Max)	250 V
Voltage Rating (AC Max)	250 V
Supply Voltage	24 VDC
	expand all
Size-Length	99 mm
Size-Width	22.5 mm
Size-Height	99 mm
Operating Temperature	-20℃ ~ 55℃
Product Lifecycle Status	Active
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
HTS Code	8536410050
ECCN Code	EAR99

Product Description

Electromechanical Relay 24VDC 400Ohm 6A (22.5x114.5x99)mm DIN Rail Safety Relay
